Renogy Pro S1 Lithium Battery With Bluetooth & Canbus - 12.8V 240Ah
Renogy Pro S1 series LiFePO4 batteries can steadily deliver over 3000W output to run 99% of appliances in your motorhomes, such as air conditioners, coffee machines and hair dryers. With strong peak output, they enable simultaneous operation of microwaves, blenders and high-power appliances.
- Rated Capacity (0.5C, 25°C): 240Ah
- Nominal Voltage: 12.8V
- Battery Cell Type: Lithium Iron Phosphate
- Cycle Life (0.5C, 25°C): 6000 Cycles (80% DOD)
- Dimensions: 405 x 244 x 188mm (15.94" x 9.61" x 7.4")
- Weight: 25.5Kg (56.21lbs)
- Protection Rating: IP67
Specifications
X| Specifications | |||
|---|---|---|---|
| Battery Cell Type | Lithium Iron Phosphate | ||
| Charge Voltage | 14.4V | ||
| Rated Capacity (0.5C, 25°C) | 240Ah | ||
| Maximum Continuous Charge Current | 240A | ||
| Nominal Voltage | 12.8V | ||
| Maximum Continuous Discharge Current | 240A | ||
| Voltage Range | 10.8V to 14.6V | ||
| Peak Discharge Current | 450A@30s | ||
| Cycle Life (0.5C/1C, 25℃) | 6000 Cycles (80% DOD) | ||
| Charge Temperature Range | -20°C to 55°C (-4°F to 131°F) | ||
| Dimension (L x W x H) | 405 x 244 x 188mm (15.94" x 9.61" x 7.4") | ||
| Discharge Temperature Range | -20°C to 60°C (-4°F to 140°F) | ||
| Weight | 25.5kg (56.21lbs) | ||
| Storage Temperature Range | -20°C to 60°C (-4°F to 140°F) | ||
| Connection Method | 4S4P | ||
| Operation Relative Humidity | 5% to 95% | ||
| Terminal Bolt Size: Terminal Bolt | M8 x 1.25 x 12 mm; Long Terminal Bolt: M8 x 1.25 x 16 mm | ||
| Recommended Terminal Torque | 70.8 in-lb / 8 N·m | ||
| Protection Rating | IP67 | ||
| Certification | MSDS, UN38.3, FCC, CE, PSE, RoHS, RCM, IC, and UKCA | ||
| Communication | Bluetooth and CAN | Storage Temperature Range | -20°C to 45°C (-4°F to 113°F) |
| Operation Relative Humidity | 10% to 95% | ||
Renogy Pro S1 series LiFePO4 batteries can steadily deliver over 3000W output to run 99% of appliances in your motorhomes, such as air conditioners, coffee machines and hair dryers. With strong peak output, they enable simultaneous operation of microwaves, blenders and high-power appliances.
Your Winter Comfort, Uninterrupted - Don't let a frozen battery leave you in the cold. With its high-wattage heating pads, the Pro S1 batteries recover from low-temperature protection up to 70% faster, guaranteeing a steady flow of power to keep you warm and meals hot during frigid days.
Built Tough for Any Trail - From city streets to rough trails, Renogy Pro S1 series batteries conquer them all. The rugged shockproof construction and brackets provide a firm grip for batteries to ensure reliable power even off the beaten path.
Power That Lasts - Coupled with an ultra-long lifespan of 6,000 cycles (retaining 80% capacity), the Pro S1 series batteries can deliver 16+ years of reliable power with one full charge cycle per day. Plus, enjoy up to 7 years of warranty for long-term peace of mind.
Unparalleled Stability - With 9 times slower temperature rise compared with traditional liquid lithium batteries, the Pro S1 series reduces the risk of thermal runaway when operating in high temperatures.
Multi-Level BMS Protections - The intelligent battery management system (BMS) deploys targeted defenses at different levels of risk. Rather than shutting everything down at once, the BMS applies the right safeguards when needed to keep your battery safe and power steady.
Fire-Retardant - Made of UL94 V-0 flame-retardant materials, the Pro S1 batteries can handle high temperatures and even 10-second burning without dripping or causing open flames.
IP67 Dustproof & Waterproof - Designed to conquer harsh environments, the Renogy Pro's IP67-rated enclosure blocks dust & water – ensuring reliable operation through sandstorms, heavy rain, or accidental splashes.
Seawater-Resistant - Engineered with marine-grade armor, Pro S1 batteries pass 24-hour salt spray tests – making them ideal power sources for sailboats, coastal homes, and offshore adventures.
Steady Data Streaming - Thanks to the enhanced Bluetooth technology, you can consistently keep track of battery stats at a maximum range of up to 32.8 yd / 30 m.
At-a-Glance Monitoring - Easily view real-time stats like voltage, current, remaining capacity, and heating status. Get instant alerts about potential risks to stay worry-free whether you're navigating miles off-grid or open waters.
Over-the-Air Update - Keep your battery at its best with new features and improvements by connecting it to the Renogy app through Bluetooth.
Maximize Your Limited Space - Save space with Pro S1 batteries that pack more energy into a smaller, lighter build. They fit neatly in motorhomes or sailboats–under seats (Pro 120Ah model), on the floor, or in cabinets–for a clean installation.
In The Box
- Pro S1 12V 240Ah LiFePO4 Battery
- Terminal Bolts (M8 x 1.25 x 12 mm)
- Long Terminal Bolts (M8 x 1.25 x 16 mm)
- Battery Fix Brackets
- Combined Bolts (M4*14 mm)
- Self-Tapping Screws (ST6.3*16 mm)
- User Manual
