Garmin GMI20 Instrument Display NMEA 0183 and NMEA 2000

Garmin GMI 20 - 4" Colour Marine Instrument

Garmin GMI 20 - 4" Colour Marine Instrument

SKU

230-0100114000

The GMI 20 digital marine instrument display is perfectly designed for both power and sail vessels. Designed to clearly show depth, speed, wind and 100+ marine and vessel parameters, its large, bright 4"" colour display with extra large digits is easy to read at a distance and has a 170 degree viewing angle.

SRP ex vat: £433.33

In stock

Product Information

Marine instrument display that clearly shows depth, speed, wind and 100+ marine and vessel parameters
Large, bright 4" colour glass-bonded lens display with anti-glare finish
Easy to read from a distance and a 170 degree viewing angle
Enhanced night time readability with backlight dimmer and full colour or new red/black or green/black colour schemes
Low profile flush mount or custom flat mount option

Specification Manual Installation Flat Mount Template Flush Mount Template

General
Dimensions	110 x 115 x 30 mm (4.33" x 4.53" x 1.18")
Weight	247 g (8.71 oz)
Water rating	IPX7
Display Type	Color QVGA display
Display Size	4" diagonal
Display Reolution	320 x 240 pixels
Mounting Options	Flat or Flush
Glass bonded display	✓
Temperature range	from -15° to 70°C

Sensors
NMEA 0183 Compatible	✓

Electrical Features
Power Consumption	3W Max
Compass Safe Distance	209mm (8.25")

Instrument Features
Auto-On	✓
User Profiles	✓
Backlight	✓

The GMI 20 digital marine instrument display is perfectly designed for both power and sail vessels. Designed to clearly show depth, speed, wind and 100+ marine and vessel parameters, its large, bright 4" colour display with extra large digits is easy to read at a distance and has a 170 degree viewing angle.

A glass-bonded lens prevents fogging and increases contrast. Daylight readability is enhanced with a high contrast colour scheme. For enhanced night visibility, you have a choice of red/black, green/black or the normal night mode colour scheme along with a dimmer control. Screens can be set to auto-scroll, cycling between pages automatically without your having to do a thing. This is especially advantageous to sailors as it allows you to install the unit(s) in a greater variety of locations on the vessel. Default profiles can be customised for powerboat, sailboat, fishing, engine/fuel, plus several other user-specified profiles. Power is supplied by the NMEA 2000 network.

In addition, the GMI 20 also features a dedicated race timer that counts down and counts up, with an internal beeper. Included are 2 trim snap piece cover options which allow you to match the GMI 20 with the new GPSMAP 500/700 series, GPSMAP 8000 Glass Helm series or legacy Garmin chartplotters.
