Scanstrut LMP-2 Self Levelling Radar Pole Mount - 2.5m
Scanstrut's Pole Leveller features a fine-tuned hydraulic damping system which reacts to major changes in heel angle of the boat. It is entirely maintenance-free and no power is required. Designed to fit the most up to date radars from Furuno.
- Height: 2.5m (8.3')
- Marine grade 6082 aluminium
- Easily removable
- Integrated cable channels
Compatible Devices
XBrand | Models |
---|---|
Furuno | 1621, 1622, 1623, 1715, 1724, 1734, 1815, 1824, 1832, 1834, 1835, DRS2D, DRS2D-NXT, DRS42DL, DRS42DL+, DRS4D / DRS4D-NXT, DRS4DL+, DRS4W, NavNet (18"), NavNet (24") |
Humminbird | AS 21RD4KW |
Interphase | Mini RE-1, RE-8, RE-9 |
JRC | 1000, 1000mk2, 1066, 1500, 1500mk2 |
Koden | 2kW 12", 4kW [RB715A] |
Lorenz | Lorenz 2kW |
Lowrance | LRA-1800 / RB714A / DX42 |
Navman | 8000 Series [8084/8120] 18" |
Nobeltec | 2kW (20") |
Northstar | M series/8000i (18") |
Seiwa | SWR-1, SWR-8, SWR-9 |
Simrad | GB40 / NX40/45 / NSE8/12 / RB712A / DX42S |
Sitex | MDS -1, MDS -8, MDS -9, MDS-12, NKE-1066 |
Techmarine | T-72.01, T-72.02, T-72.04 |
Scanstrut's Pole Leveller features a fine-tuned hydraulic damping system which reacts to major changes in heel angle of the boat. It is entirely maintenance-free and no power is required. Designed to fit the most up to date radars from Furuno.
The pole-mounted leveller comes with everything needed to install onto any sailing boat. The complete product kit includes; an adjustable base that screws into the boat at any angle, the SC100 pole, the levelling cradle with passive damping chamber and a 1200mm deck strut & 25mm rail stand-off.
Reduce Mast Weight - Keep extra weight off the mast by pole mounting a radar, it also avoids sail chafe and gives the option of installing the pole mount crane or lights on to the pole for extra flexibility.
Hydraulic Damping - The main levelling unit features a fine-tuned damping system which reacts to major changes in heel angle of the boat. It is entirely maintenance-free and no power is required.
Bespoke Mounting Pole - 2.5m (8.3’) unique pole extrusion accommodates two cable channels with a cover strip to hold cables in place and out of view.
360° Adjustable Base - The anodised aluminium base gives choice when deciding where install the pole mount. Base enables the pole to be installed on both sloping transoms and level decks.
Secure Installation - Have confidence in the installation – The pole mount is supplied with two support modules which provide maximum fore/aft and sideways support.
Removable - Unscrew the base and remove pole for racing or winter storage, leaving just low profile base on deck.
